Product Code
|
HPE ProLiant DL380 Gen9 Server
|
|
Form Factor
|
2U Rack form factor
|
|
Chassis Type
|
8 SFF & 24SFF Drive Bay Version
4 LFF & 12LFF Drive Bay Version
|
|
Processor
|
Intel Xeon E5-2699v3 2.3GHz 18 45MB 145W 9.6GT/s 2133
Intel Xeon E5-2698v3 2.3GHz 16 40MB 135W 9.6GT/s 2133
Intel Xeon E5-2697v3 2.6GHz 14 35MB 145W 9.6GT/s 2133
Intel Xeon E5-2695v3 2.3GHz 14 35MB 120W 9.6GT/s 2133
Intel Xeon E5-2690v3 2.6GHz 12 30MB 135W 9.6GT/s 2133
Intel XeonE5-2687Wv3 3.1GHz 10 25MB 160W 9.6GT/s 2133
Intel XeonE5-2683v3 2.0GHz 14 35MB 120W 9.6GT/s 2133
Intel XeonE5-2680v3 2.5GHz 12 30MB 120W 9.6GT/s 2133
Intel XeonE5-2670v3 2.3GHz 12 30MB 120W 9.6GT/s 2133
Intel XeonE5-2667v3 3.2GHz 8 20MB 135W 9.6GT/s 2133
Intel XeonE5-2660v3 2.6GHz 10 25MB 105W 9.6GT/s 2133
Intel XeonE5-2650v3 2.3GHz 10 25MB 105W 9.6GT/s 2133
Intel XeonE5-2650Lv3 1.8GHz 12 30MB 65W 9.6GT/s 2133
Intel XeonE5-2643v3 3.4GHz 6 20MB 135W 9.6GT/s 2133
Intel XeonE5-2640v3 2.6GHz 8 20MB 90W 8.0GT/s 1866
Intel XeonE5-2637v3 3.5GHz 4 15MB 135W 9.6GT/s 2133
Intel XeonE5-2630v3 2.4GHz 8 20MB 85W 8.0GT/s 1866
Intel XeonE5-2630Lv3 1.8GHz 8 20MB 55W 8.0GT/s 1866
Intel XeonE5-2623v3 3.0GHz 4 10MB 105W 8.0GT/s 1866
Intel XeonE5-2620v3 2.4GHz 6 15MB 85W 8.0GT/s 1866
Intel XeonE5-2609v3 1.9GHz 6 15MB 85W 6.4GT/s 1600
Intel XeonE5-2603v3 1.6GHz 6 15MB 85W 6.4GT/s 1600
Intel XeonE5-2699v4 2.2GHz 22 55MB 145W 9.6GT/s 2400
Intel XeonE5-2698v4 2.2GHz 20 50MB 135W 9.6GT/s 2400
Intel XeonE5-2697v4 2.3GHz 18 45MB 145W 9.6GT/s 2400
Intel XeonE5-2697Av4 2.6GHz 16 40MB 145W 9.6GT/s 2400
Intel XeonE5-2695v4 2.1GHz 18 45MB 120W 9.6GT/s 2400
Intel XeonE5-2690v4 2.6GHz 14 35MB 135W 9.6GT/s 2400
Intel XeonE5-2687Wv4 3.0GHz 12 30MB 160W 9.6GT/s 2400
Intel XeonE5-2683v4 2.1GHz 16 40MB 120W 9.6GT/s 2400
Intel XeonE5-2680v4 2.4GHz 14 35MB 120W 9.6GT/s 2400
Intel XeonE5-2667v4 3.2GHz 8 25MB 135W 9.6GT/s 2400
Intel XeonE5-2660v4 2.0GHz 14 35MB 105W 9.6GT/s 2400
Intel XeonE5-2650v4 2.2GHz 12 30MB 105W 9.6GT/s 2400
Intel XeonE5-2650Lv4 1.7GHz 14 35MB 65W 9.6GT/s 2400
Intel XeonE5-2643v4 3.4GHz 6 20MB 135W 9.6GT/s 2400
Intel XeonE5-2640v4 2.4GHz 10 25MB 90W 8.0GT/s 2133
Intel XeonE5-2637v4 3.5GHz 4 15MB 135W 9.6GT/s 2400
Intel XeonE5-2630v4 2.2GHz 10 25MB 85W 8.0GT/s 2133
Intel XeonE5-2630Lv4 1.8GHz 10 25MB 55W 8.0GT/s 2133
Intel XeonE5-2623v4 2.6GHz 4 10MB 85W 8.0GT/s 2133
Intel XeonE5-2620v4 2.1GHz 8 20MB 85W 8.0GT/s 2133
Intel XeonE5-2609v4 1.7GHz 8 20MB 85W 6.4GT/s 1866
Intel XeonE5-2603v4 1.7GHz 6 15MB 85W 6.4GT/s 1866
Intel XeonE5-2699Av4 2.4GHz 22 55MB 145W 9.6GT/s 2400
|
|
CPU Core Number
|
4to 22 core per processor, depending on processor
|
|
Max Processor Speed
|
Up to 3.5GHz per processor, depending on processor
|
|
Processor Cache Memory
|
10MB to 55MB L3 per Processor, depending on processor
|
|
Chipset
|
Intel C610 Series Chipset
|
|
System Manager
|
HPE iLO (Firmware HPE iLO4 2.0) 4GB NAND
|
|
Number Of Memory Slot
|
24 (12 DIMM slots per processor, 4 channels per processor, 3 DIMMs per channel)
|
|
RAM Storage
|
Type:
HPE SmartMemory
DDR4 Registered (RDIMM), Load Reduced (LRDIMM) or Persistent Memory (NVDIMM)
DIMM Slots Available 24 (12 DIMM slots per processor, 4 channels per processor, 3 DIMMs per channel)
Maximum Capacity (LRDIMM): 3TB (24 x 128GB LRDIMM @2400MHz)*
Maximum Capacity (RDIMM): 768GB (24 x 32GB RDIMM @2400MHz)
Maximum Capacity (NVDIMM): 128GB (16 x 8GB NVDIMM)*
NVDIMM support only with the E5-2600v4 processors, and RDIMMs only
• Note mixing of 2133 and 2400MHz memory is not supported
• Note mixing of RDIMM and LRDIMM memory is not supported
• Note the 128GB LRDIMM may not be mixed with other DIMM capacities/types
|
|
Network Controller
|
HPE Embedded 1Gb Ethernet 4-port 331i Adapter, plus optional HPE Flexi bleLOM or stand up card
|
|
Storage Controller
|
1Dynamic Smart Array B140i and/or 1Smart Array P440ar 1Smart Array P840 Depending on model
HPE Dynamic Smart Array B140i Controller
HPE Dynamic Smart Array B140i Controller
HPE Flexible Smart Array P440ar/2G FIO Controller
HPE Flexible Smart Array P840/4G FIO Controller
HPE Smart Array P840ar/2G Controller
HPE Dynamic Smart Array B140i Controller
HPE Flexible Smart Array P440ar/2GB
|
|
Drives
|
Optical Drive Ships standard in Performance Models
Optional: DVD-ROM, DVD-RW
Hard Drives: None ship standard
8 SFF with optional Universal Media Bay, 8 SFF bay or 6 NVME drive options
24 SFF plus optional 2 SFF drives rear
12 LFF plus optional 3 LFF drives rear
|
|
Power
|
HPE 500W Flex Slot Platinum Hot Plug Power Supply
HPE 800W Flex Slot Platinum Hot Plug Power Supply
HPE 1400W Flex Slot Platinum Plus Hot Plug Power Supply
|
|
System Fans
|
6 fans
|
|
Expansion Slots
|
3 slot Primary Riser (Standard) , 3 slot 2 PCIe Riser (Optional 3-slot) , 2 Slot 1 PCIe Riser (Optional 2-slot)
|
|
Hard Disk Storage
|
Hot Plug SFF SAS: 52.0TB = 24+2 x 2TB (with optional rear SFF drive cage)
Hot Plug SFF SATA: 52.0TB = 24+2 x 2TB (with optional SFF drive cage)
Hot Plug LFF SAS: 180.0TB =12+3 x 12TB (with optional rear LFF drive cage)
Hot Plug LFF SATA: 180.0TB =12+3 x 12TB (with optional rear LFF drive cage)
Hot Plug SFF SAS SSD: 397.8TB = 24+2 x 15.3TB (with optional rear SFF drive cage)
Hot Plug SFF SATA SSD:199.68TB = 24+2 x 7.68TB (with optional rear SFF drive cage)
Hot Plug LFF SATA SSD: 57.6B = 12+3 x 3.84TB (with optional rear LFF drive cage)
Hot Plug LFF SAS SSD :28.8TB = 12+3 x 1.92TB (with optional rear LFF drive cage
Hot Plug SFF NVMe PCIe SSD: 46.08TB NVMe + 36TB SFF = 6×7.68TB NVMe plus 36TB with 18 SFF (Bay 1, bay 3 and optional rear drive support)
|
|
Ports
|
Serial Video: 2 (1 front, optional via Universal Media Bay, 724865-B21), 1 back not active simultaneously
Flexible LOM Network Ports: 4 x 1Gb ports shipping standard with optional Flexible LOM
HPE iLO Remote Management Network Port : 1 Gb Dedicated
Micro SD Slot : 1 Micro SD
USB 3.0 : Up to 5 total: 1 front, 2 rear, 2 internal (secure), 2 optional USB 2.0 front via Universal Media Bay
SID (Systems Insight Display) : Optional
|
|
Operating System
|
Microsoft Windows Server
Canonical Ubuntu
Red Hat Enterprise Linux (RHEL)
SUSE Linux Enterprise Server (SLES)
Oracle Solaris
VMware
Citrix XenServer
ClearOS
|
|
Graphics
|
Integrated Matrox G200eH2 video standard with 16MB of Video RAM
• 1280 x 1024 (32 bpp)
• 1920 x 1200 (16 bpp)
HPE iLO 4 On System Management Memory
• 16 MB Flash
• 256 MB DDR3 with ECC (112 MB after ECC and video)
|
|
Security
|
Power-on password
Serial interface control
Administrator's password
UEFI
iLO 4 (Integrated Lights-Out 4) has 12 customizable user accounts and SSL encryption
Integrated Lights-Out can be disabled via a Global Setting
iLO Advanced supports directory services integration
TPM 1.2
|
|
Dimensions (HWD)
|
8 SFF & 24SFF Drive Bay Version: 3.44 x 17.54 x 26.75 in (8.73 x 44.55 x 67.94 cm)
4 LFF & 12LFF Drive Bay Version: 3.44 x 17.54 x 28.75 in (8.73 x 44.55 x 73.02 cm)
|
|
Weight
|
Minimum : 32.6 lb (14.759 kg)
Maximum : 51.5 lb (23.6 kg)
|
|
Brand
|
HPE (Hewlett Packard Enterprise)
|
|
Server Nasl
|
Gen 9
|
|
CPU Number
|
2 CPU
|
|
CPU Series
|
Intel Xeon Processor E5 v3 Family, Intel Xeon Processor E5 v4 Family
|
|
Ram Storage
|
3TB
|
|
Hard Disk Type
|
SAS, SATA
|
