Brand
|
HPE (Hewlett Packard Enterprise)
|
|
Product Code
|
HP ProLiant DL380 G10 Server
|
|
Form Factor
|
2U Rack form factor
|
|
Chassis Type
|
8 SFF with optional Universal Media Bay, and optional SFF or NVMe drive bay options
24 SFF bay with additional 6SFF rear drive bay option to total 30 SFF drives
8 LFF with Universal Media Bay
12 LFF with optional 4 LFF mid-plane and optional 3LFF + 2 SFF rear drive bay to total 19 LFF drives + 2 SFF drives
|
|
Processor
|
Intel Xeon Scalable8100/8200series
Intel Xeon Scalable6100/6200series
Intel Xeon Scalable5100/5200series
Intel Xeon Scalable4100/4200series
Intel Xeon Scalable3100/3200series
|
|
CPU Core Number
|
4to 28 core, depending on model
|
|
Max Processor Speed
|
3.9GHz, maximum depending on processor
|
|
Processor Cache Memory
|
8.25-38.50MB L3, depending on processor model
|
|
Chipset
|
Intel C621 Chipset
|
|
System Manager
|
HPE iLO 5 ASIC
|
|
Number Of Memory Slot
|
24 slots DDR4 DIMM (12DIMM slots per processor)
|
|
RAM Storage
|
Type: HPE DDR4 Smart Memory,Registered (RDIMM), Load Reduced (LRDIMM)
DIMM Slots Available : 24 , 12 DIMM slots per processor, 6 channels per processor, 2 DIMMs per channel
Maximum capacity (LRDIMM): 3.0TB , 24 x 128 GB LRDIMM @ 2933 MT/s
Maximum capacity (RDIMM): 1.54TB ,24 x 64 GB RDIMM @ 2933 MT/s
Maximum capacity (Intel Optane Persistent Memory for HPE): 6.0TB ,12 X 512 GB Memory Modules @ 2666 MT/s
Maximum capacity (HPE NVDIMMs):192 GB , 12 x 16 GB NVDIMM @ 2666 MT/s
|
|
Network Controller
|
HPE 1Gb 331i Ethernet adapter 4-ports per controller and/or optional HPE FlexibleLOM,depending on model
|
|
Storage Controller
|
1 HPE Smart Array S100i and/or 1 HPE Smart Array P408i-a and/or 1 HPE Smart Array P816i-a and/or 1 HPE Smart Array E208i-a, depending on model
|
|
Drives
|
Optical Drive
Ships standard in Performance Models
Optional: DVD-ROM, DVD-RW
Hard Drives: None ship standard
|
|
Power
|
HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
HPE 1600W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
|
|
System Fans
|
2P Models have(6)(N+1redundancy standard)
1P Models have(4)(N+1redundancy standard)
|
|
Expansion Slots
|
8 slot
|
|
Hard Disk Storage
|
Hot Plug SFF SAS HDD: 72.0 TB=24+6 x 2.4 TB* (with optional rear SFF drive cage)
Hot Plug SFF SATA HDD: 60.0 TB=24+6 x 2 TB (with optional SFF drive cage)
Hot Plug LFF SAS HDD: 311.68 TB=12+4+3 x 16 TB + 2 x 3.84 TB (with optional mid –tray and rear LFF drive cage, plus 2 SFF SSD rear)
Hot Plug LFF SATA HDD: 311.68 TB=12+4+3 x 16 TB + 2 x 3.84 TB (with optional mid –tray and rear LFF drive cage, plus 2 SFF SSD rear)
Hot Plug SFF SAS SSD: 459 TB=24+6 x 15.3 TB (with optional rear SFF drive cage)
Hot Plug SFF SATA SSD: 230.4 TB=24+6 x 7.68 TB (with optional rear SFF drive cage)
Hot Plug LFF SATA SSD: 44.16 TB=12+4+3 x 1.92 TB + 2 x 3.84 TB (with optional mid –tray and rear LFF drive cage, plus 2 SFF SSD rear)
Hot Plug LFF SAS SSD: 44.16 TB=12+4+3 x 1.92 TB + 2 x 3.84 TB (with optional mid –tray and rear LFF drive cage, plus 2 SFF SSD rear)
Hot Plug SFF NVMe PCIe SSD: 307.2 TB=20 x 15.36 TB NVMe
|
|
Ports
|
Serial: Optional, rear
Display Port: 1 (SFF 1 front, optional via Universal Media Bay, 826708-B21), 8 LFF chassis standard
Network Ports: 4 x 1GbE embedded (if equipped/depending on model)
One (1) FlexibleLOM slot available on all chassis types (supporting various NIC adapters)
HPE iLO Remote Management Network Port: 1 Gb Dedicated
Front iLO Service Port: 1 standard (Not available on 12 LFF chassis or when SID is ordered, note iLO dongle required,880123-B21)
Micro SD Slot: 1 Micro SD
Notes: The Micro SD slot is not a hot-pluggable device. Customers should not attempt to plug
an SD card into the SD slot while the server is powered.
USB 3.0: Up to 5 total: 1 front, 2 rear, 2 internal (secure), 2 optional USB 2.0 front via Universal Media Bay, or standard on 8LFF chassis
SID (Systems Insight Display): Optional
Notes: Not shipping as standard. Available as a CTO option or as a field upgrade (826703-B21)
|
|
Operating System
|
Microsoft Windows Server
VMware ESXi
Red Hat Enterprise Linux (RHEL)
SUSE Linux Enterprise Server (SLES)
Citrix
|
|
Graphics
|
Integrated Video Standard
Video modes up to 1920 x 1200@60Hz (32 bpp)
16MB Video Memory
|
|
Security
|
Optional locking Bezel Kit, Intrusion Detection Kit, and HPE TPM 2.0
|
|
Dimensions (HWD)
|
44.55 x 73.03 x 8.74 cm (17.54 x 28.75 x 3.44 in)
|
|
Weight
|
14.76 kg (32.6 lb)
|
|
Server Generation
|
Gen 10
|
|
CPU Number
|
2 CPU
|
|
CPU Series
|
Legacy Intel Xeon Processors
|
|
Ram Capacity
|
1.54 TB
|
|
Interface
|
SAS, SATA
|
